GCL P10 Full Color LED Digital Signage Display Mesh LED Display With Wide Viewing Angel

Contact Now
Shenzhen GCL Electronics Co., Ltd
Visit Website
City:shenzhen
Province/State:guangdong
Country/Region:china
Contact Person:MrBill
Contact Now

GCL P10 Full Color LED Digital Signage Display Mesh LED Display With Wide Viewing Angel

Ask Latest Price
Video Channel
Place of Origin :Guangdong, China
Model Number :Gsurface-III
Brand Name :GCL
Packaging Details :Packing with Flight case & Wooden box & Hard paper box
Supply Ability :5000 Square Meter/Square Meters per Month
Price :Negotiable
MOQ :Min. order: 20
Certification :EMC/CE/ROHS/CCC/FCC/BIS
Delivery Time :15-20Days
Application :Outdoor
Color :FULL COLOR
Panel Size :320*320mm
Supplier Type :ODM, OEM
Media Available :EDA/CAD Models
use :advertising publish, display of dishes
Pixel Pitch :8mm, P3.91 P4.81 P5.92 P8
Specification :Digital Poster, Video Wall
Usage :Outdoor Waterproof
Display Function :Animation
Brightness :6000nits
Protection level :IP65
Viewing angle :140/140 Degree
Refresh rate :1920Hz-3840Hz
LED chip :Nationstar
Cabinet material :Iron
Control system :Novastar
Warranty :3 Years
Port :Shenzhen
more
Contact Now

Add to Cart

Find Similar Videos
Full Color Outdoor Fixed LED Display 01:34
Full Color Outdoor Fixed LED Display
High Definition Outdoor Advertising Screen 05:41
High Definition Outdoor Advertising Screen
High Definition Outdoor LED Video Wall With 1/4 Scan Mode And 6mm Pixel Pitch 00:19
High Definition Outdoor LED Video Wall With 1/4 Scan Mode And 6mm Pixel Pitch
Curved Flexible Round Outdoor Fixed LED Display P5.7 1/6 Scan Method Outdoor Display Screen 02:45
Curved Flexible Round Outdoor Fixed LED Display P5.7 1/6 Scan Method Outdoor Display Screen
High Brightness Outdoor Fixed LED Display 00:46
High Brightness Outdoor Fixed LED Display
Commercial Transparent LED Display Board For Outdoor Advertising Size 256*128mm 00:44
Commercial Transparent LED Display Board For Outdoor Advertising Size 256*128mm
Iron Cabinet Full Color Outdoor Fixed LED Display SMD P6 Screen Naked Eye 3D Viewing 00:45
Iron Cabinet Full Color Outdoor Fixed LED Display SMD P6 Screen Naked Eye 3D Viewing
Indoor Narrow Pixel Pitch COB HD LED Display For School Classroom P0.9 00:24
Indoor Narrow Pixel Pitch COB HD LED Display For School Classroom P0.9
View Product Description
GCL P10 Outdoor Full Color LED Digital Signage Display with 140/140 Degree Viewing Angle

Product Details

Low Power Consumption
We use customized PCB and power supply, so average power consumption is less than 140W/㎡. Compared with the similar products in the market, the display saves 20% energy. The pixel pitches are P5.92P6.67P8P10P10 DIP P16(DiP)

High Brightness

Gold bonding wire DIP LED with stable driving IC ensures the high brightness of 10,000nits and long lifespan of modules.

High Refresh Rate
The image on the LED screen is formed perfectly. One of the reasons is that the refresh rate can reach 3,840Hz.

High Protective Grades

3 layers of high-quality conformal coating protects the driving IC and other electron components from dust and humidity. Strong signal cable brings more security and the cables look neat.

Great Gray Scale
Most LED screens from other suppliers have a low gray scale, so some of the colors can't be displayed on the screen, and the image on the LED screen appears like a ghost image. Our LED screen grays cale is 13bits ~ 16bits. It is very high so the image looks very vivid and perfect.

Product parameters


Name P5.92 P6.67 P8 P10 P10B P16
LED Type SMD2727 SMD2727 SMD2727 SMD2727 DIP346 DIP346
Pixel Pitch(mm) 5.925 6.667 8 10 10 16
Module Resolution 54*54 48*48 40*40 32*32 32*32 20*20
Module Size(mm) 320*320 320*320 320*320 320*320 320*320 320*320
Scan Method 1/6s 1/6s 1/4s 1/2s 1/4s 静态
Module Quantity 4*3 4*3 4*3 4*3 4*3 4*3
Cabinet Resolution 216*162 192*144 160*120 128*96 128*96 80*60
Cabinet Size(mm) 1280*960*100;Customizable
Cabinet Area(㎡) 1.2288
Cabinet Material Profile Aluminum
Cabinet Weight 32kg 32kg 32kg 32kg 37kg 35kg
Density(pixels/㎡) 28476 22500 15625 10000 10000 3096
Protection Level IP65
Optics





Brightness(nits) 6500 6500 7000 7000 10000 10000
Calibration Support Single-dot Calibration
Color Temperature 1700-9500K Adjustable
Viewing Angle H140°,V140°
Light Decay Rate <3%
Contrast Ratio 9000:01:00
Grey Scale 13-16bit
Max Power Consumption/㎡ 640W 700W 680W 680W 360W 420W
Average Power Consumption/㎡ 220W 230W 230W 230W 120W 140W
Cabinet Maintenance Full Front/Rear Service
Input Voltage AC100~240V(50-60Hz)
Drive Mode Constant Current Drive
Refresh Rate 3840Hz
Frame Rate 60Hz
Working Temperature/Working Humidity -20~+60/ 10%-90%RH
Storage Temperature/Storage Humidity -20~+60/ 10%-90%RH
Certifications EMC/CE/ROHS/CCC/FCC/BIS

FAQ
Q1. Is GCL a manufacturer or a trading company? Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty? The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms? Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time? Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.

Q5. Do you provide any free spare parts in each order? Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED diod, IC, module mask, power supply, receiving card, etc.
